Type1-Without LTE

Type2-With LTE Cat4 (EG95-NA) for North America

Type3-With LTE Cat4 (EC25-J) for Japan

Type4-With LTE Cat4 (EG95-E) for the EMEA region (Europe/Middle East and Africa)

Type5-With LTE Cat4 (EC25-E) for Thailand /india

Type6-With LBT for Japan /Without LTE

Type7-With LTE Cat4 (EC25-AU) for Latin America/Australia/New Zealand

Type8-With EU plug/ Without LTE

Type9-With EU plug /With LTE Cat4 (EG95-E) for the EMEA region (Europe/Middle East and Africa)

Type10-With UK plug/Without LTE

Type11-With UK plug/ With LTE Cat4 (EG95-E) for the EMEA region (Europe/Middle East and Africa)

Type12-With LBT for korea / Without LTE

Type13-With LTE Cat4 (EC25-E) for South korea



This advanced gateway supports 8 LoRa channels and offers versatile backhaul connectivity options, including Ethernet, Wi-Fi, and Cellular. The breathing light LED provides a clear visual indication of the device's operational status, ensuring you can quickly assess its functionality at a glance.

The RAK7268V2/CV2 runs on WisGateOS 2, RAK's unified operating system that offers improved management and utility features. It retains all the robust functionalities of the original WisGateOS while adding new options and intuitive tooltips. Additionally, it supports extension add-ons for additional features and management. Read more about WisGateOS 2 here.

For remote management, the WisGate Edge Lite 2 integrates seamlessly with the WisDM platform, allowing you to monitor, control, and update your gateway from anywhere. This feature makes it an ideal choice for smart buildings, smart offices, smart factories, and many other use cases.

With its quick and seamless deployment capabilities, the RAK7268V2/RAK7268CV2 ensures a solid out-of-the-box experience. Whether you need rapid deployment or extensive customization in terms of UI and functionality, this gateway is the perfect fit.

Note: Due to hardware limitations, gateway variants with LBT (Listen Before Talk) do not support cellular connectivity options. If your deployment requires both LBT functionality and Cellular connectivity, you can consider WisGate Connect.

Product Features

Hardware

  • 8 LoRa channels

  • Supports 2.4 GHz Wi-Fi AP for configuration

  • 100M Base-T Ethernet with PoE

  • 12V DC power supply

  • RP-SMA LoRa antenna connector

  • Multi back-haul with Ethernet, Wi-Fi, Cellular(RAK7268CV2)

  • SD card for log backup and LoRa frame buffering (in case of backhaul failover)

  • LTE Cat 4 network (optional)

  • Breathing light for visual monitoring the status

Software

  • WisGateOS 2

  • Extension add-ons

  • Built-in Network Server

  • LoRaWAN 1.0.3 (LoRaWAN 1.0.4 for the Built-in server is coming soon)

  • Basics Station and Packet forwarder

  • LoRa Frame filtering (node whitelisting)

  • MQTT v3.1 Bridging with TLS encryption (compatible with ChirpStack LNS)

  • Buffering of LoRa frames in Packet Forwarder mode in case of NS outage (no data loss)

Note: A model of WisGate Edge Lite 2 version 2 RAK7268V2/RAK7268CV2 with support for 9~24V DC power input is available upon request. For further information about this specific model or to make a purchase, please contact us at inquiry@rakwireless.com.

Package Inclusions

  • 1pc Gateway

  • 1pc LoRa antenna

  • 1pc Power supply

  • 1pc mounting bracket

Documentation



Packaging Details

  • Unit Type:
  • Package Weight: 0.750
  • Package Size: 20x9x26

  • Brand Name: RAK
  • Hign-concerned Chemical: None
  • Type: Wireless
  • Origin: Mainland China
  • Style: Internal
