0.1MHz ~ 1200MHz frequency meter PLJ-1601-C frequency components of the frequency measurement display module
ID: 65879

0.1MHz ~ 1200MHz frequency meter PLJ-1601-C frequency components of the frequency measurement display module

0.0 ( votes)
Price: US $40.45 / piece
Discount Price:
US $ 39.22 / piece

0.1MHz ~ 1200MHz frequency meter PLJ-1601-C frequency components of the frequency measurement display module


  • Use 8 bit Microchip PIC16F876A,up to 1.1GHz
  • Gate time
    0.01 seconds
    0.1 seconds
    1.0 seconds
  • Measuring channels ( high and low channels are high impedance )
1)Low channel

Measuring range : 0.1MHz ~ 70MHz
Measurement accuracy:
± 100Hz ( 0.01 seconds gate )
± 10Hz ( 0.1 seconds gate )
± 1Hz ( 1.0 seconds gate )
0.1MHz ~ 10MHz: better than 50mVPP
10MHz ~ 60MHz: superior to 50mVPP
60MHz ~ 75MHz: not tested
 2)High channel frequency (64 points )
Measuring range : 10MHz ~ 1.1GHz
Measurement Accuracy : ± 6400Hz (0.01 seconds gate )
± 640Hz ( 0.1 seconds gate )
± 64Hz ( 1.0 seconds gate )
High channel sensitivity : 10MHz ~ 30MHz: better than 100mVPP
30MHz ~ 60MHz: superior to 50mVPP
60MHz ~ 1.1GHz: not tested
Automatic channel is automatically selected based on the frequency of the input signal level of channel
Crystal measuring channel
Measuring range : 1 MHz ~ 50 MHz ( the most low-end and highest end untested )
3) . Frequency reference
5032 package 13.000 MHz Warming voltage controlled crystal oscillator ( VC - TCXO) , frequency stability is ± 2.5 ppm
IF settings
The minimum frequency is adjustable in steps of 100 Hz, frequency range 0 ~ 999.9999 MHz, can be set to plus or minus IF mode
  • working voltage

    DC input: DC 9V ~ 12V
  • working current

    The backlight is enabled: ≤ 75 mA backlight disabling: ≤ 55 mA
  • Display
    maximum of 9 digit display
  • physical dimensions

    Length * width * height:  92mm × 37mm × 27mm
  • Board interface

    RF INPUT (measuring signal input): XH2.54-2P curved needle square socket
    ICSP INPUT (MCU interface): XH2.54-6P curved needle square socket
    ECL INPUT (external clock input): XH2.54-2P curved needle square socket
    POWER INPUT (Power Interface):  with 3.5mm socket (DC is negative)
    The XH2.54-2P curved needle square socket

  • Brand Name: HQXRTEK
  • Compatible Devices Brand: Other
  • Origin: Mainland China
  • Item Type: MP3 Players Accessories Kits
  • Function: Other
  • type: Signal Frequency Counter
  • module: PLJ-1601-C
  • range: 1MHz- 1200MHz
