OneChipBook -12-A FPGA development platform
4.8 (26 votes) | 103 orders
Price:
US $
809.08
The package includes: OneChipBook-12-A main unit × 1,USB-Type-C cable × 1
Important Notice:
The OneChipBook is a blank FPGA development platform with no predefined functionalities. It is exclusively designed for FPGA engineers or individuals actively learning hardware programming.
Before placing an order, please ensure that you have reviewed the OneChipBOOK-12_Technical_Referenceand confirmed your capability to develop and utilize FPGA.
Schematics and user manuals:
www.8086cpu.com
Overview
The OneChipBook-12 is an FPGA development platform centered around the Cyclone EP1C12Q core. It integrates a VGA monitor(LCD form iPAD2), PS/2 mechanical keyboard, battery, and I/O ports. All peripheral devices are connected to the FPGA's general-purpose I/O pins, allowing users to control the entire system by developing for a single chip without complex interface design.
OneChipBook-12 has two order numbers. They share identical keyboard scan codes, with the only difference being the keyboard silkscreen markings.
OneChipBook -12 (12k Les) - A (Keyboard layout A)
OneChipBook -12 (12k Les) - B (Keyboard layout B)
Features
- FPGA: Cyclone EP1C12Q240
- 12,060 Les
- 239,616 bits RAM
- 32MB SDRAM
- 1024x768 VGA monitor
- VGA/S-Video/CVBS Output interface
- Mechanical keyboard (PS/2)/ Backlight
- Stereo speakers
- Type-C charging port
- Lithium battery
- Expansion Bus Support
Packaging Details
- Unit Type:
- Package Weight: 1.650
- Package Size: 23x7x32
- Brand Name: MAPCVB
- Battery Included: Yes
- Origin: Mainland China
- Hign-concerned Chemical: None
- Model Number: MSXBOOK
