JINYUSHI For SIM7020 SIM7020E New&Original Multi-Band B1/B3/B5/B8/B20/B28 LTE NB-IoT SMT type M2M module compatible with SIM800C

5.0 (1 votes) | 4 orders
Price:
US $ 22.60 / piece
Quantity





If you need SIM7020E development board. Please Click

Package list:

SIMCOM SIM7020E LCC * 1 PCS




The SIM7020 is Multi-Band NB-IoT module solution in a SMT type .
It has strong extension capability with rich interfaces including UART, GPIO etc. The module provides much flexibility and ease of integration for customer's application.
The package of SIM7020 is compatible with SIM800C. This also minimizes the investments of customers, and enables a short time-to-market.
It is designed for applications that need low latency, Low throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for M2M applications, such as metering, asset tracking, remote monitoring , E-health etc..
Key Benefits
● With Power Save Mode(PSM) and Extended Discontinuous Reception(eDRX), SIM7020 can extend battery life to 10 years
● SIM7020 provides deeper coverage enhancement compared to GSM
● The package and AT commands of SIM7020 mostly are compatible with SIM800C.
General features
• SIM7020C: B1/B3/B5/B8
• SIM7020E: B1/B3/B5/B8/B20/B28
• Control Via AT Commands
• Supply voltage range: 2.1V-3.6V
• Operation temperature: -40°C to +85°C
• Dimensions: 17.6 X 15.7 X 2.3mm
• Weight: 1.3g±0.2g
Data
• Uplink: 62.5Kbps
SMS
• Downlink:26.15Kbps
• Text and PDU mode
Consumption
• PSM: 5 uA
* In development
Other Features
• Firmware update via UART
• TCP/UDP
• LWM2M/COAP*
• MQTT
• FTP/HTTP/HTTPS*/SSL*/DTLS*
• FOTA *
• PSM/eDRX
Interfaces
• UART
• SIM card (1.8V/3V) GPIO
• ADC
• Netlight
• PSM_EINT
• Reset
• Powerkey
Certifications(plan)
• CCC / TA / CTA (SIM7020C)
• CE/GCF (SIM7020E)
• RoHS / REACH

Payment:We can accept all payment by Escrow.




1. We can ship to all over the world.Items will be shipped within 1-3 business days after we verify your payment.

2. Please tell me your current address after your payment within 1-2 days; otherwise, we will ship your item based on your Escrow address, so make sure it is correct.

3. Before ordering please contact us to confirm your preferred shipment method. Normally, it takes 7-30 business days for arrival by Air Mail, and takes 3-10 business days by Express such as DHL UPS FEDEX EMS TNT and so on.

4. Sometimes it would be longer because of the bad weather, a waste of time in customs clearance. Thus please wait patiently when you do not receive your item on time. If you don't receive the item within thirty days, please contact us, and then I will help you track it

.

1. Please confirm the receipt of the products after you get them.

2. If you have any question for the products you received, please contact us in time and we will try our best to solve the problems and make you satisfied.

3. Please kindly not forget to  give us the positive feedback for 5 star.


  • Package: Yes
  • Products Status: STOCK
  • Interface Type: LCC
  • Model Number: SIM7020E
  • wirless Modem Type: WCDMA
  • Style: Internal
  • Type: Wireless
  • Brand Name: JINYUSHI
  • Certification: NONE
  • Origin: Mainland China
